24-portno stikalo s (16) 802.3at PoE + vrati, (8) 802,3bt PoE ++ vrati in (2) 10 GB SFP + vrati.
Zmogljivo preklapljanje UniFi druge generacije!
UniFi Switch Pro 24 PoE je popolnoma upravljano stikalo Layer 3 z (8) 802.3bt (PoE ++) in (16) 802.3at (PoE +) Gigabit Ethernet vrati.
2) Povezave 10G SFP + ponujajo združevanje povezav za večjo zmogljivost in večjo razpoložljivost.
UniFi Switch Pro 24 PoE ima bogat nabor možnosti Layer 2 in vključuje funkcije Layer 3, kot so usmerjanje med VLAN, statično usmerjanje in strežnik DHCP.
Omrežni krmilnik UniFi in mobilna aplikacija UniFi Network skrbnikom omogočata konfiguriranje in spremljanje tako rekoč vseh funkcij stikal v intuitivnem grafičnem uporabniškem vmesniku od koder koli.
Lastnosti:
(8) Gigabitna vrata RJ45 802,3bt PoE ++
(16) Gigabitna vrata RJ45 802.3at PoE +
(2) 10G SFP + vrata
Funkcije sloja 2 in sloja 3
400 W največja moč PoE
UniFi SmartPower RPS DC vhod
Skoraj tiho hlajenje
1,3-palčni zaslon na dotik
Upravljanje preko UniFi Network Controller programske opreme
| Mechanical | |
| Dimensions | 442.4 x 285.4 x 43.7 mm |
| (17.42 x 11.24 x 1.72") | |
| Weight | 4.30 kg (9.48 lb) |
| With Rackmount Brackets | 4.39 kg (9.68 lb) |
| Interfaces | (24) 10/100/1000 RJ45 Ports |
| Networking | (2) 1/10G SFP+ Ethernet Ports |
| Management | Ethernet In-Band |
| Power Method | |
| Universal Input | 100-240VAC/50-60 Hz |
| USP RPS DC Input | 52VDC, 7.69A; 11.5VDC, 2.61A |
| Power Supply | AC/DC, Internal, 450W |
| Supported Voltage Range | 100 to 240VAC |
| Max. Power Consumption (Excluding PoE Output) | 50W |
| LEDs | |
| System | Status |
| RJ45 Data Ports | PoE; Speed/Link/Activity |
| SFP Data Ports | Link/Activity |
| ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 10 to 90% Noncondensing |
| Certifications | CE, FCC, IC |
| Sound Level* | |
| 25% PoE Load, 25° C Room Temperature | 0.9 dBr |
| 50% PoE Load, 25° C Room Temperature | 7.3 dBr |
| 100% PoE Load, 40° C | 18.8 dBr |
| PoE | |
| PoE Interfaces | |
| Ports 1-16 | POE+ IEEE 802.3af/at, (pins 1, 2+; 3, 6-) |
| Ports 17-24 | 60W PoE++ IEEE 802.3bt, (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 8-) |
| Max. PoE Wattage per Port by PSE | |
| 802.3at | 32W |
| 802.3bt | 64W |
| Voltage Range 802.3af Mode | 44-57V |
| Voltage Range 802.3at Mode | 50-57V |
